Model | KM-TRI02E |
Size | 1200*280*980mm |
Material | GB304 |
Pass Width | 550mm |
Passage direction | Bi-directional |
Pass rate | 30-35 persons/minute |
Operating time | 0.2 seconds |
Power input | AC100-240V,50/60HZ |
Working voltage | 24V |
Working humidity | 30%~95% |
Working temperature | -40℃~+70℃ |
Working environment | Indoor/outdoor |
Communication interface | RS485, 12v Dry contact, Relay |
Mechanism | Mould machine core+mould bracket+Domestic solenoid |
Product function:
1. Unique incomplete wheel transmission is adopted to make
turnstiles held or unheld in zero position more accurate and
reliable.
2. Running stable, little noise and no mechanical impact
3. Self-checking-power-on function, if power on, turnstile will
auto get to be held.
4. Various working means can be set in the control panel menu,
5. If power off, arm will fall automatically while power on later,
arm should be lift by hand. First press the arm with a little force
and then lift it manually.
6. RS485 connection for far control arm up and down to satisfy the
special needs or fire control requirement.
7. It is with standard electrical interface to connect various
kinds of readers and writers for easy integration and also
computer far control and management can be realized by computer.
8. It will count the pedestrian and will show the number on LED
display directly. (LED is optional)
FAQ:
1.Will you install the channel lock for the first time?
Answer: on channel brake installation is very simple, just put the
product fixed well, main machine and insert 110V/220V power supply,
can normal use, if you need to connected to the Internet, only need
to use a network line can be received from the main computer, we
will provide all the one-on-one phone technology Guidance services.
2.Can machines be used outside?
Answer:It can be used outside. We all have waterproof function.
3.What is the warranty for the machine?
Answer: (1) we guarantee all goods quality assurance for two years.
(2) within the two years warranty time,if the machine have
problem,we can offer you the accessories(but you pay the freight
cost)
4.When will you make the delivery?
Answer:regular products:(3-5 days),irregular products:communication
when you place the order.
5.Payment term?
Answer:30% by T/T in advance.70% by T/T before delivery.
