304/316 Stainless Steel Servo Motor Control Speed Gate Turnstiles
Introduction:
Speed Gate as pedestrain turnstile, can better meet the needs of a
variety of traffic, where
widely used in airports, subway stations, stations, high-end
community, office building, School ,hotel, factory etc.can
also be used with smart cards/ barcode/ fingerprint/ consume
system/ face recognition etc to achieve offline ticket management
System functions.
Parameter:
| Lane length (mm) | 600 / 900 Acrylic or Temperated glass |
| Min/max width of passage clearance (mm) | 1,250 / 1,850 |
| Max gate-leaf opening (°) | 90 |
| Material | 2.0 thickness 304/316 stainless steel |
| Pass speed | 30-40 people / Min |
| Power supply | (V - 50/60 Hz) 120 - 230 AC |
| Motor power supply (V) | Servo Motor |
| 90° opening speed (s) | 0.2s |
| Power (W) | 120 |
| Operating temperature (°C) | -20 ÷ +55 |
Features:
1. Door will keep opened automatically while power cut off.
2. Direction adjustable, one-way or bi-direction, by RFID Card,
Barcode, Face recognition or Infrared Sensor.
3. With direction indication, guiding passenger to entry and exit.
4. Anti-pinch function
5. Anti-tail, prevent people follow pass without verified
6. Use super capacitor instead of backup battery for gate open with
electric cut off, without shipping
problem with battery. (battery model available also)
7. Prevent wrong direction pass, go through wrong direction will be
alarm by beep
8. Option RFID access controller, fingerprint reader, facial
identify reader, qr code reader, barcode
reader, consume system.
9. Self automatic locking to prevent force passing without the card
10. Light and sound alarm indication function, preventing illegal
entry or irregular passing
Spotlights:
1.Innovative design and exquist maching to meet the high end access
control solution
2.Fast pass speed Turnstile to ensure an orderly access of 35-45
people per minute
3.Easy operation and free maintenance
FAQ:
1.What's the MOQ?
The MOQ of the tripod turnstile is 1pc/pair
2.Whether the size and shape of turnstile can be changed?
Yes, we can redesign the size and shape of the turnstile
to meet your requirement.
3.Is the parts of turnstile available?
If you order our turnstile, the parts can be offered.
4.About the OEM and ODM
Our turnstile can be label your logo to meet your requirement.
5.About the warranty and after-sales services
We provide one year warranty and all life after-sale service,
if require, we can dispatch our engineer to the spot to
help you
6.About the package
For turnstile, carton package first, then wooden case package
to make sure if won't be damaged in the process of transportation.
7.About the installation
We provide the manual to help you to install our turnstile,
as for the software, we provide team viewer to install the
software. Any help will be provided to meet your needs.
8.About the delivery time
5-7 days after payment received
9.About the term of delivery
Support EXW, FOB,etc.
Case:
