Intelligent Servo Motor Fastlane Speed Gate Turnstile

    Buy cheap Intelligent Servo Motor Fastlane Speed Gate Turnstile from wholesalers

    Buy cheap Intelligent Servo Motor Fastlane Speed Gate Turnstile from wholesalers
    • Buy cheap Intelligent Servo Motor Fastlane Speed Gate Turnstile from wholesalers

    Intelligent Servo Motor Fastlane Speed Gate Turnstile

    Ask Lasest Price
    Brand Name : KOMAI
    Model Number : KM-SW39
    Certification : ISO, Rohs, CE, FCC
    Price : Negotiable
    Payment Terms : T/T, Western Union
    Supply Ability : 5000pcs per month
    Delivery Time : 3-7 working days
    • Product Details
    • Company Profile

    Intelligent Servo Motor Fastlane Speed Gate Turnstile

    Intelligent Servo Motor Fastlane Speed Gate Turnstile


    Features and Benefits


    • Safety first: In the fire or power-off,the door can be free to promote and ensure unimpeded
    • Various Interfaces: I/O, RS232/485,CAN interfaces, which it is convenient to control signal input, and provides convenient centralized fire control interface.
    • Two working modes: NC and NO, which is easy to deal with peak and normal use.
    • Multiple control modes: There are unidirectional, bidirectional, free passage and authorization passage to meet fully the users ‘needs, which consist of nine control modes;
    • Precise positioning: precise positioning by photoelectric sensors, the work cycle of door is regular and precise positioning to ensure correct position after long work;
    • Sensor Analysis:The sensor got signal which real-time processing and analyzing a person or object for a variety of action, according to the results of analysis are to accurately control the action of machine core, indicator and alarm etc.
    • Convenient setttings: With the screen and buttons consist of human-machine interface, the users can quickly and easily query and set channel parameters,no longer totally dependent on the host computer or extremely unfriendly pure key board to query and set parameters. This is not necessary functions, but once experience we believed that no one will forget it is great.

    Parameters of Fastlane Speed Gate Turnstile

    Name:Fastlane Speed Gate Turnstile
    Dimensions:1600x120x1000mm
    Materials:304/316 stainles steel (more than 1.5mm)
    Opening time:0.2 seconds
    Infrared:5 logarithms
    Lane width:≤900mm default 600mm
    Throughput:35 person /minute
    Voltage:AC220±10%V 50HZ
    Motor:DC motor 24V
    Power:35W
    Temperature:-25~+70ºC
    Applicable environment:Indoor/outdoor (rainproof shed without ponding) outdoor)
    Relative humidity:≤90%,No condensation
    Communication interface:RS485 Electrical standards ; ≤1200 meter / TCP-IP

    Functions:


    1.working method can be set by the buttons on the main panel
    2.Anti-pinch, anti-collision. If there is block during return of gate, motor stops working automatically. Reset again after a
    default delay, the force 2Kg.
    3.Anti-illegal in, anti-intrusion, auto close for reverse direction.
    4.Anti-collision, gate closes when no valid signal is given.
    5.Protection functions for gate, gate open to prevent motor from being damaged if there is outer force collision.
    6.Gates can be synchronous
    7.Auto-reset. If not go through in a preset time, pass right would be cancelled automatically. (1-60s adjustable), default time is 10s.


    Available areas:
    Public transportation (Train Stations, Metro Stations, etc…)
    Government Offices
    Public Offices
    Business Building Centers
    Schools
    Hospitals
    Stadiums
    Sports Centers
    Industrial Buildings


    FAQ:

    1. Can you install RFID card reader on the turnstile?

    Yes,except the RFID card reader system,we also can install fingerprint reader system,token system,esd system,etc.

    2. How about the guarantee and after sale service?

    We have 12 month quality guarantee, We own well-trained and passional sales & after- sale services who can speak fluent English language

    3. How long is the leading time?

    For standard item
    10-50 sets:5 working days
    50-100 sets:7-10 working days
    200-500 sets:10-15 working days
    For special item, or need custom design package or logo, need 3-10 working days longer

    4. How about the payment terms?

    TT,western union,L/C,our company already joined the trade assurance,it will highly protect your order security.

    5. How do you send the product to me,how long?

    For sample,normaly send by air or express,about 3-5 days

    For quantity purchase,normally by sea, it normally takes 7-60 days depend on different countries.

    6. Can you do OEM service?

    We offer below OEM services:

    1)We can make custom design turnstile,or you tell me your requirements ,we can make a design for you.

    2)Can print your logo on turnstiles, can customize the retail box packing and other things.
