SUS304 Pedestrian Gate Tripod Barriers For Access Control

Product Details:

Production process: full computer numerical control laser cutting machine

Production weight: (vertical type 40kg), (bridge type70kg)

Maximum bearing force of brake rod: 80kg

Driving force of brake rod: 3kg
The brake lever steering: one-way, two-way (optional); with a variety of working modes to choose, i.e. two-way card reading and current limiting; one side card reading and the other direction prohibition, while reading card and the other direction free passage

Functions of Pedestrian Gate Access Control Tripod Turnstile Gate

1). Running stably without noise and mechanical impact

2). The number of the passing persons can be counted via the built-in people counter

3). Several ways of working modes for option

4). Bi-direction or one direction permitted. One forbidden. Or one direction charged.

One for free . And all the working modes set by the buttons in the main control board

5). Beam falling and lifting can be controlled in far distance so to satisfy the special require ment of the users and the request of fire protection

6). LED Direction-guide lights in the turnstile to tell you whether the direction to go or not

7).The standard electrical interface connected with various kinds of reader and writer equipments

8). All the functions realized in one integration machine and controlled and managed by the computer in the far distance

9). The number of the persons passed can be counted automatically which can also be display in LED

10). The function with or without card-reading memory can be set according to your demand

11). Self-check and alarm for convenient to operate

Features:

1. GB 304 stainless steel sheet metal forming, beautiful, durable
2. Dimensions : 1200*280*980 (mm)
3. Channel width: less than 550 (mm);
4. Brake lever steering : one-way, two-way (optional)
5. Control mode: manual/ automatic (optional)
6.Support HDMI external large screen;
7.Support night light fill;
8.Support external QR code scanner and ID card reader (currently only supports the excellent card reader ID-R21 serial version);
9.Support serial port, Wiegand 26, 34 output, output content support configuration;
10.Adopt dynamic face detection and tracking recognition algorithm based on video stream
11.Support device local storage mega-bank, support simultaneous storage of 20,000 face photos (photos are calculated in 100KB), 10,000 identification records (including on-site snapshots);
12.When the face database is 3000, the recognition rate of 1:N is 99.7% under the condition of three-thirds of the misunderstanding rate;
13.Fast recognition speed, (a) face tracking and detection takes about 20ms (b) face feature extraction takes about 200ms (c) living body detection face time takes 0.2ms (1000 people library, multiple recognition Average), 0.5ms (10000 people database, multiple recognition average);
14.Support for stranger detection, stranger level configurable;
15.Support for live photo preservation when face recognition or stranger detection;
16.Support LAN deployment mode;
17.Support HTTP interface interface docking;
18.Support screen display content configuration;
19.Support for identifying distance configurations.

Compatibility:

◆ Material, surface treatment and appearance style size
◆ Integrated access control system
◆ Integrated ticketing system
◆ Integrated camera system
◆ Integrated temperature control system
◆ Install remote control button
◆ Install LED counter (optional built-in or external)
◆ Waterproof and dustproof design: IP65 Typical application:
◆ Office locations: smart buildings, commercial buildings, government agencies, etc.
◆ Science and education units: schools, colleges, research institutes, libraries, etc.
◆ Commercial service places: supermarkets, shopping malls, hotels, clubs, banks, etc.
◆ Residence: residential area, community, apartment, dormitory, etc.
◆ Transportation site: subway, airport, etc.

FAQ:

1.Will you install the channel lock for the first time?

Answer: on channel brake installation is very simple, just put the product fixed well, main machine and insert 110V/220V power supply, can normal use, if you need to connected to the Internet, only need to use a network line can be received from the main computer, we will provide all the one-on-one phone technology Guidance services.

2.Can machines be used outside?

Answer:It can be used outside. We all have waterproof function.

3.What is the warranty for the machine?

Answer:(1) we guarantee all goods quality assurance for two years.

(2) within the two years warranty time,if the machine have problem,we can offer you the accessories(but you pay the freight cost)

4.When will you make the delivery?

Answer:regular products:(3-5 days),irregular products:communication when you place the order.

5.How does your factory control the quality?

Answer:We always attach great importance to quality controlling from the beginning to the ending.

6.What is your MOQ?

Answer:Any quantity is acceptable for your order. And the price is negotiable for big quantity.

7.payment term?

Answer:30% by T/T in advance.70% by T/T before delivery.
